| Categories | PC Blow Molding Machine |
|---|---|
| Place of Origin: | JIANGSU, CHINA |
| Brand Name: | TONGDA |
| Certification: | CE, ISO9001 |
| Packaging Details: | PE film, PE bag, Wooden Cases, Wooden Pallet, etc. |
| Supply Ability: | 800sets/year |
| Price: | $89,999.00 - $119,999.00/Sets |
| MOQ: | 1SET |
| Delivery Time: | 28 working days |
| Payment Terms: | T/T, L/C, D/P, West Union |
| Model Number: | TONGDA TDB25APC |
| Machinery Test Report: | Provided |
| Core Components: | PLC, Bearing, Motor, Pressure vessel, Pump |
| Application: | Bottle |
| Plastic Processed: | PP, HDPE, PC, PVC, PE, Tritan |
| Year: | 2019 |
| Voltage: | 220~440 |
| Dimension(L*W*H): | 6.3*2.2*3.8m |
| Hollow part volume: | 5gallon |
| Clamping Force (kN): | 215 |
| PLC Brand: | MITSUBISHI |
| Screw L/D Ratio: | 38 |
| Screw diameter (mm): | 82 mm |
| Output (kg/h): | 160 kg/h |
| Automation: | Automatic |
| No. of Screw Heating Zone: | 4 |
| Screw Heating Power(kW): | 40 kW |
| Extruder Motor Power(kW): | 50 kW |
| Mold Platen Size(Width)(mm): | 550 mm |
| Mold Platen Size(Height)(mm): | 650 mm |
| Air Pressure(MPa): | 0.6 MPa |
| Air Comsumption(m³/min): | 1 m³/min |
| Die Head Heating Power(kW): | 9.5 kW |
| Accumulator Capacity(L): | 1.9 L |
| Power (kW): | 106 |
| Weight (T): | 12 |
| Key Selling Points: | use TRITAN and automatic |
| Warranty: | 1 Year |
| Applicable Industries: | Food & Beverage Factory, Food Shop, Food & Beverage Shops |
| Showroom Location: | Egypt, Indonesia, Pakistan, Thailand, Chile, Algeria |
| High Pressure Valve Brand: | AirTac |
| Rotary Cylinder Brand: | AirTac |
| After-sales Service Provided: | Field maintenance and repair service, Field installation, commissioning and training, Video technical support, Online support |
| After Warranty Service: | Video technical support, Online support, Spare parts, Field maintenance and repair service |
| Local Service Location: | Egypt, Indonesia, Pakistan, Thailand, Chile, Algeria |
| Port: | Shanghai port |
Product Description
This TDB-25APC extrusion blow molding machine is suitable for 25L
product and it is bottom blow. The die-head is accumulator. It
equipped with servo motor.
Technical Parameters
MODEL | Units | TDB-25APC | Remarks: If you have other special requirements,we can provide
customized services for you. |
Max. Product volume | L | 25 | |
Output of HDPE | kg/h | 16 | |
Clamping force | kn | 215 | |
Screw diametre | mm | 82 | |
Screw heating power | kw | 40 | |
Blow pressure | mpa | 0.6 | |
Size of machine | m | 6.3-*2.2*3.8 |
Product Details
Bottom Blowing Unit, with high precission of component assembly, can also be equipped with down seal device
Upper parison sealing device, stable and reliable
Die head:Excellent flow channel technology and precise machining accuracy, make the color change and material change more efficient. From dark to white, normally can be completed within 3hours. Much quicker than other suppliers. Save cost for you if you need to produce different color products.
Company Information
Now we have more than 50 R & D personnel, including 1 national science and technology talent, 4 senior masters,15 bachelors, hosting the development of two national standards and participating in the formulation of a national standard.
FAQ
TONGDA sales consultant
1. We can provide comprehensive and professional Suggestions on
equipment selection.
2. Energy consumption calculation and investment income analysis
can be provided.
3. Provide tailor-made CAD drawings of workshop layout and product
optimization Suggestions.
4. Extrusion plastic bottle blow molding machine has remote
maintenance function
Advantages of TONGDA tech teams
1. 800 sets of customized requirements per year enable us to have
rich experience across multiple industries.
2. Customize equipment models according to customer product
characteristics.
3. Project responsibility system, closed-loop team cooperation
between the design team and the process team, adjustment of the
team, and joint creation of equipment that users are satisfied
with.
4. Engineers can study abroad or participate in technical function
training of the industry to master the latest information and
technical trends of the industry.
5. Undertake a number of large projects, and has a group of senior
technical personnel composed of the construction team, can build
cable bridge, installation of a complete set of equipment.
Advantages of TONGDA after-sales team
1. Lifetime free service for the machine.
2. Quick response all day long.
3. Set up domestic service team and international service team.
4. Technicians also master the debugging and maintenance of
auxiliary equipment.
5. A free 2-day training course will be provided to customers every
year.
6. Special processing equipment to produce after-sales accessories
to ensure rapid response to user needs.
|
