| Categories | Vehicle Lithium Ion Battery |
|---|---|
| Brand Name: | Pinsheng Energy |
| Model Number: | PE72200 |
| Certification: | CE , MSDS , UN38.8 , ISO9001 |
| Place of Origin: | China |
| MOQ: | 1 |
| Price: | USD 3098 - 3328 / pc |
| Payment Terms: | L/C , D/A , D/P , T/T , Western Union , MoneyGram |
| Supply Ability: | 10000pcs / month |
| Delivery Time: | 10 - 20days |
| Packaging Details: | carton box , UN box , wooden box |
| Product Name: | 72V 200Ah Electric Vehicle EV Motor Battery |
| Material: | Cold Steel |
| Size: | 1010* 341 * 300 mm |
| Weight: | 132Kgs |
| Voltage: | 72Volts |
| Capacity: | 200Ah (Amp) |
| Charging cut off voltage: | 60Volts |
| Discharging: | 84Volts |

72V 200Ah 14.4KWh Motorbike Battery 15kw Electric Vehicle Lithium ion Battery Pack EV Battery
Model: PE72200
Parameters:
1. Product Name: 72V 200Ah Electric Vehicle Battery Pack
2. Dimension: 1010.8 (L) * 340 (W) * 301 (T) mm
3. Weight: 132.5Kgs
4. Material: Steel
5. Color: OEM Customized
6. Working Voltage: 73.6Volt
7. Capacity: 200Ah
8. Charging Cut Off Voltage: 200Volt
9. Discharging Limit Voltage: 400Volt
10. Battery Cell: NCM or LFP(LiFePO4)
Application
Widely use for E-bike , Electric Motorbicycle , Electric Vehicle, AGV
| Item | Detail |
|---|---|
| Product Name | 72V EV Batteries |
| Series - Parallel Mode | 20S2P |
| Cycle Life | 3500 Times 100% DOD 4500 Times 80% |
| Dimension | 1010.9mm (L) * 341mm (W) * 299m( H ) |
| Weight | 133Kgs |
| Battery Box Material | Steel |
| Color | Black White Colorful |
| Working Voltage | 72 V |
| Capacity | 200 Ah (AMP) |
| Charging Cut Off Voltage | 60 V |
| Discharging Limit Voltage | 84 V |
| Battery Cell | NCM |
| Working Temperature | -21~ 61°C |
| Charging Temperature | 0 ~ 56℃ |
| Working Humidity | <85 % |
| Internal Resistance | 1.1mΩ |
| Self Discharging Rate | 3% |
| OEM / ODM | Accepted |
| Charging / Discharging Interface | According to customer's like |








|
