| Categories | Optical Rotary Encoder |
|---|---|
| Brand Name: | HXC |
| Model Number: | MicroE-CE300 |
| Certification: | CE |
| Place of Origin: | China |
| MOQ: | 10 |
| Price: | Negotiable |
| Payment Terms: | Western Union, T/T, L/C |
| Supply Ability: | 5000 |
| Delivery Time: | 5-8 work days |
| Packaging Details: | Carton or according to customer requirements |
| Type: | MicroE Encoders |
| Resolution: | Up To 22 Bit |
| Power Supply: | 5VDC ±0.5 VDC |
| Input Voltage: | 5VDC± 0.5 |
| Supply Current: | 30mA, unterminated outputs |
| Weight: | 0.37 g (CE300), 0.25 g (CE) |
| High Light: | Absolute Rotary Encoder、Rotary Shaft Encoder、Zettlex Inductive Encoders、Optical Rotary Encoder |
MicroE CE300 Optical Rotary Encoder For High Performance High Volume Designs
| PAD NUMBER | SIGNAL | FUNCTION |
| 1 | IW- | Index Window Channel |
| 2 | GND | Ground |
| 3 | NC | No Connect |
| 4 | NC | No Connect |
| 5 | CP+ | Raw Index Signal |
| 6 | +5VA | Supply Voltage |
| 7 | NC | No Connect |
| 8 | GND | Ground |
| 9 | DC2 | Reference Threshold 2 |
| 10 | CA | Laser Cathode |
| 11 | DC1 | Reference Threshold 1 |
| 12 | NC | No Connect |
| 13 | AN | Laser Anode |
| 14 | Sin+∗ | Sinusoidal Alignment Reference |
| 15 | NC | No Connect |
| 16 | NC | No Connect |
| 17 | NC | No Connect |
| 18 | GND | Ground |
| 19 | +5VD | Supply Voltage |
| 20 | B+ | B Quadrature Channel |
| 21 | B- | B Quadrature Channel |
| 22 | A+ | A Quadrature Channel |
| 23 | A- | A Quadrature Channel |
| 24 | IW+ | Index Window Channel |
Aura Rotary Glass Scale Part Numbers
| Scale Part Number | Inner Diameter | Outer Diameter | Counts Per Rev (CPR) | Corresponding Chip Part Number |
| AUR-R-G-0001 | 12.0 mm | 26.0 mm | 256 | AUR-R-B-0001-WP |
| AUR-R-G-0002 | 7.0 mm | 18.0 mm | 172 | AUR-R-B-0002-WP |
| AUR-R-G-0003 | 21.0 mm | 33.0 mm | 343 | AUR-R-B-0003-WP |
| AUR-R-G-0004 | 49.0 mm | 63.5 mm | 908 | AUR-R-C-0004-WP |
| AUR-R-G-0006 | 38.0 mm | 51.8 mm | 761 | AUR-R-C-0006-WP |
| Scale Part Number | Scale Measuring Length | Overall Length | Thickness | Corresponding Chip Part Number |
| AUR-L-G-0001 | 9.0 mm | 16.0 mm | 2.29 mm | AUR-L-C-0000-WP |
| AUR-L-G-0002 | 50.0 mm | 57.0 mm | 2.29 mm | AUR-L-C-OOOO-WP |
| AUR-L-G-0004 | 195.0 mm | 202.0 mm | 2.29 mm | AUR-L-C-OOOO-WP |
Optical Rotary Encoder Applications:
3C Electronics, Robotics, Medical Devices, Semiconductors, Airborne Devices, Etc.
FAQ:
Q: What’s your MOQ?
A: 1pcs
Q: How to order your encoder?
A: Contact us, or email us, we will reply you as soon as possible.
Q: Can you product ship to our country?
A: Yes, please advise your destination and zip code, we will check freight cost for you immediately.
Q: How to get the latest price?
A: Contact us and tell me the encoder model selection.
Q: How to select a right encoder model?
A: A right encoder model is based on different applications and parameters, you could contact us for technical support if you have any query.
Q: Do you offer technical support?
A: Yes, we have professional technician who can solve all your doubts.
Q: Can you factory offer a sample?
A: Yes, sample can be provided.
Q: How to pay for a sample?
A: Currently, our factory accept L/C, T/T, Western Union.
Q: What’s your encoder product guarantee policy?
A: 1 year quality warranty and life-long technical support.
If you have any doubt on selecting the model, you are welcome to contact us for more assistant.
|
