ASTM JIS SUS420J1 AISI 420 20Cr13 Hot Rolled Stainless Steel Plate Thickness 10mm 30mm

AISI 420 Stainless Steel (SS420), UNS S42000

AISI 420 stainless steel (SS420) is a straight chromium martensitic stainless steel grade with certain wear resistance, corrosion resistance and high hardness.

SS420 Datasheet

The tables below give 420 stainless steel (SS420) datasheet and specification including chemical composition, properties, heat treatment, etc.

Chemical Composition

Datasheet 1, The table below shows ASTM AISI 420 stainless steel composition.

AISI 420 Stainless Steel Properties

The datasheets below list type 420 stainless steel (SS420) properties including physical properties and mechanical properties.

Physical Properties

SS 420 stainless steel physical properties are listed in the table below such as density, melting point, specific heat, electrical resistivity, elastic modulus, thermal conductivity, and coefficient of thermal expansion (CTE).

Datasheet 2, 420 stainless steel properties – 1.

Mechanical Properties

AISI 420 stainless steel mechanical properties are given in the datasheet below including tensile strength, yield strength, elongation, reduction in area, Brinell and Rockwell hardness, Charpy impact test, etc.

Datasheet 3, Type 420 stainless steel properties – 2.

Type 420 Stainless Steel Heat Treatment

Type 420 stainless steel heat treatment includes annealing, hardening, tempering and stress relief. Preparation for heat treatment includes precleaning, preheating, atmosphere protection, salt bath, and hydrogen embrittlement.

• Precleaning: All workpieces of SS420 and fixtures must be thoroughly cleaned, such as oil, sweat and other stains on the surface of the workpiece.
• Preheating: The thermal conductivity of type 420 stainless steel is usually lower than that of carbon steel. When heating rapidly, the workpiece is easily deformed and cracked. Therefore, preheating is recommended. The preheating temperature is generally 760-790 °C (1400-1450 °F). Heavy-duty parts can be preheated in two stages: Preheat at 540 °C (1000 °F) firstly, and then heat to 790 °C (1450 °F).
• Atmosphere protection: Austenitizing temperature 1010 °C (1850 °F), dew-point temperature: 10-12 °C (50-54 °F) for AISI 420 wrought martensitic stainless steel.
• Salt bath: Bath salts give 420 grade stainless steel (SS 420) parts a better result.
• Hydrogen embrittlement: Hydrogen embrittlement is a serious problem with 420 steel.

Annealing

Annealing for ASTM AISI 420 wrought stainless steel.

• Subcritical annealing (Recommended) temperature for AISI 420 stainless steel: from 675-760 °C (1245-1400 °F); Air cool from the temperature range, use the upper heating temperature range to minimize hardness. The corresponding Rockwell hardness is 94-97 HRB.
• Full annealing temperature for type 420 steel: 830-885 °C (1525-1625 °F), and then soak thoroughly, furnace cool to 790 °C (1455 °F), continue cooling at 15-25 °C/h (27-45 °F/h) to 595 °C (1100 °F); Air cool to room temperature. The corresponding Rockwell hardness is 86-95 HRB.
• Isothermal annealing temperature for AISI 420 grade stainless steel: Heat to 830-885 °C (1525-1625 °F); keep 2h at 705 °C (1300 °F), the corresponding Rockwell hardness is 95 HRB. (Preheat at subcritical annealing temperature range is very important.)

Hardening

Hardening for 420 grade stainless steel: Heating to austenitizing temperature 980-1065 °C (1800-1950 °F), quenching medium is air or oil, if the part thickness is > 0.25 in. (6.4 mm), oil quenching should be used. After quenching to room temperature, immediate cold treatment is recommended and the recommended cold treatment temperature is -75±10 °C (-100±20 °F), which can reduce austenite and keep maximum dimensional stability.

Company Overview ：

The company has an indoor warehouse of 5000 square meters and an open warehouse of 4000 square meters, which can fully meet the temporary turnover and phased storage of customers' steel pipe reservation.

The subordinate processing plant has 6 sets of medium frequency heating fully automatic thermal expansion units, 5 sets of fully automatic groove processing machines, 1 set of processing and drying integrated painting equipment imported from Germany, 1 set of streamlined anti-corrosion processing equipment and 1 set of streamlined thermal insulation processing equipment; The steel pipe can be processed, cut, hot expanded or cold drawn according to the needs, so as to fully meet the customized needs of users.

Main products :

We can supply various kinds of metal material, like carbon steel seamless pipe, alloy tube, fertilizer tube, spiral tube, ductile iron pipe, cryogenic tube, special pipe for cold storage and galvanized Steel.
Our products can be used in various applications over a wide range of industries, like chemical, petrochemical, oil and gas, pharmaceutical, food processing, power generation, aviation, marine and so on.

Sales Performance and Network :

The annual sales volume of the company is more than 300000 tons, and the sales volume has reached new highs. The company has formed a complete sales service system based on East China and facing customers all over the country. The company has a good reputation, high-quality products, strong strength, low price reputation in the country, products are deeply dependent on users. The company's products not only sell well in the domestic market, but also sell well in the United States, Canada, Colombia, the United Arab Emirates, Thailand, India, Vietnam, Pakistan, South Korea, Japan, Russia and other countries and regions, and are well received by foreign customers. The number of export countries is growing, and the sales volume is gradually increasing.
