Name: Deye 8Kw 10Kw 12Kw 16Kw 20Kw Hybrid Inverter 3 Phase 5Kw Off Grid Solar Inverter Eu Manufacturers
Brand: Deye
Price: 1 USD

Home > Scanners >

Deye 8Kw 10Kw 12Kw 16Kw 20Kw Hybrid Inverter 3 Phase 5Kw Off Grid Solar Inverter Eu Manufacturers

Categories	solar Inverter
Place of Origin:	Guangdong, China
Brand Name:	Deye
Model Number:	5kw 6kw 8kw 10kw 15kw
Input Voltage:	1000v
Output Voltage:	220/380v 230/400v
Output Current:	10-20A
Output Frequency:	50/60Hz
Output Type:	Three Phase
Size:	408638237mm
Type:	DC/AC Inverters
Inverter Efficiency:	98%
Certificate:	CE Rosh, FCC
Warranty:	5/10Year
Weight:	31kg
Product name:	Deye Hybrid Solar Inverter
Application:	Solar Power System Home
Inverter type:	Hybrid Grid Inverter
Protection:	Overload Protection
Output Power:	5KW/6KW/8KW/10KW/12KW
Display:	LCD
Keyword:	Inverter Solar
Battery type:	Lead Acid \ Lithium \ Gel
MPPT voltage range:	120V-1000V/600V
Communication:	WIFI / RS485
Packaging Details:	We will according your product select the most suitable packaging according to the quantity.
Supply Ability:	10000 Piece/Pieces per Week
Price:	$1,256.00/pieces 1-9 pieces

Contact Now

Add to Cart

Product Details
Company Profile

Deye 8Kw 10Kw 12Kw 16Kw 20Kw Hybrid Inverter 3 Phase 5Kw Off Grid Solar Inverter Eu Manufacturers

Products Description

Model	SUN-5K -SG04LP3-EU	SUN-6K -SG04LP3-EU	SUN-8K -SG04LP3-EU	SUN-10K -SG04LP3-EU	SUN-12K -SG04LP3-EU
Battery Input Data
Battery Type	Lead-acid or Lithium-ion
Battery Voltage Range (V)	40-60
Max. Charging Current (A)	120	150	190	210	240
Max. Discharging Current (A)	120	150	190	210	240
External Temperature Sensor	Yes
Charging Curve	3 Stages / Equalization
Charging Strategy for Li-Ion Battery	Self-adaption to BMS
PV String Input Data
Max. DC Input Power (W)	6500	7800	10400	13000	15600
Rated PV Input Voltage (V)	550(160-800)
Start-up Voltage (V)	160
MPPT Voltage Range (V)	200-650
Full Load DC Voltage Range (V)	350-650
PV Input Current (A)	13+13					26+13
Max. PV Isc (A)	17+17					34+17
No.of MPP Trackers	2
No.of Strings per MPP Tracker	1					2+1
AC Output Data
Rated AC Output Active Power (W)	5000	6000	8000	10000	12000
Max AC Output Active Power (W)	5500	6600	8800	11000	13200
AC Output Rated Current (A)	7.6/7.2	9.1/8.7	12.1/11.6	15.2/14.5	18.2/17.4
Max AC Output Current (A)	8.4/8	10/9.6	13.4/12.8	16.7/15.9	20/19.1
Max. Three-phase Unbalanced Output Current (A)	11.4/10.9	13.6/13	18.2/17.4	22.7/21.7	27.3/26.1
Max Output short circuit current (A）	75
Max. Continuous AC Passthrough (A)	45
Peak Power (off grid)	2 time of rated power, 10 S
Power Factor	0.8 leading to 0.8 lagging
Output Frequency and Voltage	50/60Hz; 3L/N/PE 220/380, 230/400Vac
Grid Type	Three Phase
Total Harmonic Distortion (THD）	＜3% (of nominal power)
DC current injection	＜0.5%In
Efficiency
Max. Efficiency	97.60%
Euro Efficiency	97.00%
MPPT Efficiency	99.90%
General Data
Operating Temperature Range (℃)	-40~60℃, >45℃ derating
Communication with BMS	RS485; CAN
Weight (kg)	33.6
Size (mm)	422W x 702H x281D
Installation Style	Wall-mounted

Product Details

Company Profile

1,Q:Why your quotation is higher than other suppliers? A:In domestic market, the high and low inverter brands are mixed together. There are many low-cost inverter is actually some assembled small unlicensed workshops, it crudely, to reduce costs and use of substandard components for assembly, there is a very big security risk! In order to protect the pro personal and property safety, please do not covet low price, be sure to choose a reliable inverter! .............................................................................................................................................................. 2,Q:How many categories does it have according to the output waveform ? A:Type one: Modified Sine Wave inverter, which uses PWM pulse width modulation to generate modified sine wave. Due to the usage of intelligent dedicated circuit and high power field effect tube, it greatly reduces the power loss and increases the soft-start function, effectively ensuring the reliability of the inverter. If the power quality is not highly demanded, it is able to meet the needs of most electrical equipment. But it still exists 20% harmonic distortion problems when running sophisticated equipment, can also cause high-frequency interference to radio communications equipment. This kind of inverter can meet the basic needs of most of our power, high efficiency, small noise, moderate price, and thus become the mainstream products in the market. Type two: Pure Sine Wave inverter, which adopts isolated coupling circuit design, high efficiency, high stability of the output waveform, high-frequency technology, small in size, suitable for all kinds of load, can be connected to any common electrical devices and inductive load devices (such as refrigerators, electric drill, etc.) without any interference (eg: buzz andTV noise). The output of pure sine wave inverter is the same as the grid tie power we daily used, or even better, because it does not exist grid tie electromagnetic pollution. .............................................................................................................................................................. 3,Q:Is the output voltage of our inverter stable ? A:Absolutely. Our inverter is designed with a good regulator circuit. You can even check it when measuring the true value by a multimeter. Actually the output voltage is quite stable. Here we need make a especial explanation : many customers found it is unstable when using conventional multimeter to measure voltage. We can say the operation is incorrect. Ordinary multimeter can only test pure sine waveform and calculate datas. .............................................................................................................................................................. 4,Q:What is a resistive load appliances? A:Generally speaking, appliances like mobile phones, computers, LCD TVs, incandescents, electric fans, video broadcast, small printers, electric mahjong machines, rice cookers etc. All belong to resistive loads. Our modified sine wave inverters can drive them successfully. .............................................................................................................................................................. 5,Q:What is the inductive load appliances? A:It refers to the application of electromagnetic induction’s principle, produced by high-power electrical products, such as motor type, compressors, relays, fluorescent lamps, electric stove, refrigerator, air conditioner, energy saving lamps, pumps, etc. These products’power are far more than the rated power (about 3-7 times) when start. So only pure sine wave inverter is available to them. .............................................................................................................................................................. 6,Q:What should be noticed when installing inverter? A:Put the product in a place where is well ventilate,cool, dry and water-proof. Pls do not stress and do not put foreign objects into the inverter.Rember to turn on the inverter before turn on the appliance.
