High Efficiency 48V Home Energy System Ac To Dc Pure Sine Wave Inverter Off Grid Split Phase Hybrid Solar Inverter

Categories	Off Grid Energy Storage
Place of Origin:	Guangdong, China
MOQ:	negotiated
Price:	negotiated
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time:	negotiated
Cycle life:	5000 cycles
Rated AC input voltage:	220VAC/230VAC/240VAC
Warranty:	5 Years
Output Voltage (V):	6V
Weight:	6kg~9.2kg

Contact Now

Add to Cart

Product Details
Company Profile

High Efficiency 48V Home Energy System Ac To Dc Pure Sine Wave Inverter Off Grid Split Phase Hybrid Solar Inverter

Product parameters

Model	10212	20224	30248	50248
Rated Power	1000W	2000W	3000W	5000W
Output Voltage	220VAC	220VAC	220VAC	220VAC
Output Frequency	50/60Hz	50/60Hz	50/60Hz	50/60Hz
Input Voltage	220VAC	220VAC	220VAC	10000VA
Input Frequency	50/60Hz	50/60Hz	50/60Hz	50/60Hz
Maximum AC Charge Current	10A	30A	30A	30A
Maximum PV Array Power	400W	1600W	3200W	3200W
Max PV Input Voltage(Voc)	150VDC	150VDC	150VDC	150VDC
MPPT Tracking Voltage Range	15-150VDC	6030-150VDC	60-150VDC	60-150VDC
Maximum PV Charge Current	30A	60A	60A	60A
Battery Voltage	12VDC	24VDC	4848VDC	48VDC
Operating Temperature	-15℃-50℃	-15℃-50℃	-15℃-50℃	-15℃-50℃
Storage Temperature	-20℃-50℃	-20℃-50℃	-20℃-50℃	-20℃-50℃
Dimension	420x321x125mm	545x461x170mm	545x461x170mm	545x461x170mm
Net Weight	6kg	8kg	8.8kg	9.2kg
Warranty	3 years	3 years	3 years	3 years
Packing Size (CM)	51.53820.5	64.555.526	64.555.526	64.555.526
G.W/CTN (KGS)	7kg	9kg	9.8kg	10.2kg

FAQ

Q1. Can I get the sample order?
A: Yes. welcome sample order to test and check quality. Mix sample are acceptable.
Q2. Do you offer guarantee for the products?
A: Yes, we offer 5 year warranty for the product.
Q3: How do you guarantee the quality of the battery ?
A: We will test all the battery Voltage and Internal resistance.We will mark basic specification on the battery before shipping.

Q4: What’s the payment terms?
A: We accept T/T, Paypal, western union.
Q5: Why Choose Our Products?
1. Good Quality.
2.Factory direct price.
3.Small MOQ.
4.OEM&ODM acceptable
