Chewing Gum Plastic Blister Pack Sealing Machine 45 Cutting / Min

Categories Automatic Blister Packing Machine
Brand Name: HUALE MACHINERY
Model Number: DPP-250A
Certification: CE ISO9001
Place of Origin: CHINA
MOQ: 1 Set
Price: Negotiation
Supply Ability: 15 Set per month
Delivery Time: 30 working days after received your payment.
Packaging Details: WOODEN BOX.
Name: Blister Packing Machine
Output: Max.45cutting/min
Used: Pill or Capsule or Tablet etc.
System: PLC Touch Screen
Noise: Low
Option Parts 1: Vision inspection system
  • Product Details
  • Company Profile

Chewing Gum Plastic Blister Pack Sealing Machine 45 Cutting / Min


Chewing Gum Plastic Blister Pack Sealing Machine 45 Cutting / Min


Introduction:


PLC control system, touch screen with Chinese/English language.

  1. Wide application
  2. High quality
  3. Easy to operate

Performance and characteristics:


1. This machine gets the function for easy cutting line embossing, batch number embossing, trace pressing and wasted packaging material rewinding.

2. The step motor is adopted on the machine for precise controlling the pulling length and saving material.

3. The heating molds of the machine will automatically separate when the machine stops, which contributes to protect the packing material from the heated mold.

4. The mold and the automatic feeder can be designed according to customer’s request.


TECHNICAL PARAMETER


Item Model

DPP-350A

DPP-250A

DPP-140A

Cutting Frequency

(ideal sizes:80*57mm)

15-45 cutting/min

15-45 cutting/min

15-45 cutting/min

Max. Forming Area and Depth

350×130×15

250×120×15

140×110×15

Adjustable Scope of Travel(mm)

30-140mm

30-130mm

30-120mm

Packaging material

(I.D.Φ75)

PVC(mm)

(0.15-0.6)

×350×(Φ400)

(0.15-0.4)

×260×(Φ400)

(0.15-0.4)

×160×(Φ350)

PTP(mm)

(0.02-0.15)

×350×(Φ400)

(0.02-0.15)

×260×(Φ400)

(0.02-0.15)

×160×(Φ350)

Paper(mm)

(50-100)g/㎡

×350×(Φ400)

(50-100)g/㎡

×260×(Φ400)

(50-100)g/㎡

×160×(Φ350)

Power

380V 50Hz 9.5kw

380V 50Hz 8kw

380V 50Hz 5.5kw

Air compression

(Don't Provide)

0.6-0.8Mpa

≥0.6m³/min

0.6-0.8Mpa

≥0.45m³/min

0.6-0.8Mpa

≥0.4m³/min

Recycle water or

circulating water consumption

60-100L/h

40-80L/h

40-80L/h

Overall Dimension(L*W*H)(including foundation)

3650×850×1700

2900×750×1600

2400×650×1450

Dimension of Each Part

1850×850×1700(front)

1500×750×1600(front)

1350×650×1250(front)

1800×850×1650(back)

1400×750×1450(back)

1050×650×1450(back)

Weight

About 2000kg

About 1200kg

About 800kg
