| Categories | Outdoor LCD Digital Signage |
|---|---|
| Brand Name: | TOPADKIOSK/OEM |
| Model Number: | TPK-OF4365 |
| Certification: | CE&Rohs&FCC |
| Place of Origin: | CHINA |
| MOQ: | 1PC |
| Price: | negotiate |
| Payment Terms: | T/T, , MoneyGram |
| Supply Ability: | 3000pcs per month |
| Delivery Time: | 10-15days after receipt of your payment |
| Packaging Details: | Packed in carton firstly,and then reinforced with wooden case for outer packing |
| Pnale size: | 43 inch |
| Brightness: | 1500-5000nits |
| Panel: | 50000hours |
| Material: | Galvanized steel with anti-reflect glass |
| Max Resolution: | 1080*1920 |
| Touch screen: | optional |
| Air condition: | for optional |
| Connectivity: | LAN, WIFI, 3G(Optional) |
| Fan cooling system: | Yes |
High Brightness Free Standing Digital Signage Outdoor 43 Inch 49
Inch 55 Inch
1. Outdoor application
2. Sunshine readable, high brightness 2000 nits, auto dimming.
3. Waterproof
4. Anti- thief, Anti dust.
5. Application areas can be public bus station, out of shopping
mall, store, etc.
6. Certication: IP65 level
7. Built-in air conditioner and fans optional.
| Specifications | |||||||||
| Panel size | 42" | ||||||||
| Display area(mm)/mode | 930(W)*523(H) 16:9 | ||||||||
| Maximum resolution | 1920*1080 | ||||||||
| Display color | 16.7M | ||||||||
| Pixel Pitch(mm) | 0.4845(H)*0.4845(V) | ||||||||
| Brightness (nits) | 2000cd/m2 | ||||||||
| Contrast | 4000:1 | ||||||||
| Visual angle | 178°/178° | ||||||||
| Response time | 5ms | ||||||||
| Life(hrs) | >60,000(hrs) | ||||||||
| Input and output | |||||||||
| LAN | RJ45 (for Network version) | ||||||||
| WIFI Module | 1 (for Network version) | ||||||||
| USB | 1 | ||||||||
| SD | 1 | ||||||||
| Speaker | 2*10W(9Ω) | ||||||||
| Video | |||||||||
| Color system | PAL/NTSC/SECAM | ||||||||
| Remote controller | IR Remote Controller | ||||||||
| OSD display( screen menu display) | |||||||||
| Menu language | Chinese/English | ||||||||
| Power | |||||||||
| Power supply | AC100~240V 50 /60 HZ | ||||||||
| Maximum power consumption | <=220W | ||||||||
| Standby power consumption | <5W | ||||||||
| Temperature | |||||||||
| Working temperature | 0℃~50℃ | ||||||||
| Storage temperature | -20℃~60℃ | ||||||||
| Working humidity | 85% | ||||||||
| Storage humidity | 85% | ||||||||
| Appearance | |||||||||
| Color/appearance | White,black,customized | ||||||||
| Case | Metal case SPCC | ||||||||
| Installation | Floor-standing | ||||||||
CPU: Allwinner A83T Cortex-A7 Eight-Core CPU 2GHz/RK3288
GPU: PowerVR SGX544
O/S: Android 4.4.4
RAM: 2GB
NAND FLASH: 8GB FLASH/EMMC
Networking: RJ45
Built-in Wireless 802.11b/g/n,WAPI(Ralink 8188)
USB Wireless Dongle
Interface: USB*2,SD*1,VGA*1,RJ45*1,Audio out*1,SIM port*1
Ports: USB*2,SD*1,VGA*1,RJ45*1,Audio out*1,SIM port*1
OSD Language: Chinese, English, Spanish, Russian, German, French, Arabic, etc.
Support split screen: Any split screen display, multiple window video player, can
achieve different window showing different content
Processor: Intel Core i3-3217U @ 1.80GHz /I5 /I7
GPU: Intel HD4000 Graphics
Chipset: Intel Chipset HM65
Memory: DDR3 4GB ,Support up to 8GB
Ethernet: Realtek GBE RJ45,8111E
Audio: Realtek HD Audio,Support Line-in,Line-out,Mic-in,Spdif,Speaker
Display: VGA1,LVDS.
Storage: 128G SSD
Touch technology: capacitive touch
Touch model: 10 touch points
Induction object: Finger, pen, any opaque objects
Size of induction: Greater than or equal to 5 mm in diameter
Resolution: 8192*8192
Response time: First point 25ms consecutive points 8ms
Cursor speed: ≥200dots/second
Glass Thickness: 4mm Normal or Anti-glare tempered glass
Application
1. Public Places: Subway, Airport, Bookshop, Exhibition hall,
Gymnasium, Museum, Conference
center, Talent market, Lottery center, etc.
2. Entertainment Places: Movie theatre, Fitness center, Vacational
village, KTV bar, Internet bar,
Beauty salon, Golf course, etc.
3. Financial Institution: Bank, Security/ Fund/ Insurance company,
etc.
4. Business Organizations: Supermarket, Shopping malls, Exclusive
shop, chain store, 4S shop,
Hotel, Restaurant, travel agency, Chemist's shop, etc.
5. Public Service: Hospital, School, Telecom, Post office, etc.
6. Real Estate&Property: Apartment, Villa, Office building,
Commercial office buildings, Model
houses, Sales offices, the entrance of elevator, etc
|
