| Categories | Pneumatic Solenoid Valve |
|---|---|
| Brand Name: | PRIUS,XINYI or OEM |
| Model Number: | 5V3220 |
| Place of Origin: | Ningbo,China |
| MOQ: | 50pcs |
| Price: | negotiation |
| Payment Terms: | T/T, L/C, Western Union,Paypal |
| Supply Ability: | 5000pcs per month |
| Delivery Time: | 10~15 working days |
| Packaging Details: | bag+box+catons+pallet |
| name: | air solenoid valve |
| Working Medium: | air/oxygen/rare gases |
| Max Pressure: | 0.4Mpa |
| Pressure Range: | 0~0.35Mpa |
| Temperature Range: | -5~60℃ |
| Port Size: | G1/4" |
| Net Weight: | 0.4kg/pcs |
| Voltage: | DC12V,DC24V |
| Class of Insulation: | F class |
| Cv: | 0.89 |
5V3220 ~ 5V5220 SMC Type 3 Way Solenoid Valve , Mini Pneumatic Air Valve With Double Coils
Specifiction
| Model | MP-08 |
| Medium | air/oxygen/rare gases |
| Pressure IN-port1.2-OUT1.2 | Min:0.001Mpa |
| Service pressure range | 0~0.35Mpa |
| Max operating pressure | 0.4Mpa |
| Effective cross-sectional arer | 16mm2 |
| Cv value | 0.89 |
| Ambient temperature | (-5~60c°) |
| Operating fluid temperature | (-5~50c°) |
| Allowable inside lerkage | pressure=0.2Mpa ≤0.1/min |
| Allowable outside lerkage | pressure=0.2Mpa ≤0.1/min |
| Mounting posture | According to our design |
| Response time | ON=≤0.1MS OFF=≥0.1MS |
| Noise level | |
| Life cycles | ≥10 million times |
| Allowable voltage fluctuation | DC12V DC24V |
| Range of allowable voltage | ±15% |
| Power consumption | 1W |
| Class of Insulation | F class |
| Protective struchure | IP65/IEC/DIN40050 |
| Piping thread | G1/4" |
| Lead wire length | produce as requested |
| Dimensions Mounting | 71.3mm*42mm*64.3mm(h) |
| Material | aluminium alloy brass |
| Net Weight | 0.4kg/pcs |
|
