Part Number | FEO- 381 | FEO-444 | FEO-570 | FEO-667 | FEO-800 | FEO-1000 |
Pixel Pitch (mm) | 3.81 | 4.44 | 5.7 | 6.66 | 8 | 10 |
Panel Density (dot/m²) | 63504 | 50630 | 30625 | 22500 | 15625 | 10000 |
Panel Resolution(dot) | 126*84 | 108*72 | 84*56 | 72*48 | 60*40 | 48*32 |
Cabinet Size(mm) | 960*960*83 | 960*960*83 | 960*960*83 | 960*960*83 | 960*960*83 | 960*960*83 |
Cabinet Resolution(dot) | 252*252 | 216*216 | 168*168 | 144*144 | 120*120 | 96*96 |

Cabinet Weight | 25kg |
IP Rating(Front /Back) | IP65 |
Brightness Intensity | >10000 CD/m² |
Viewing Angle(H/V) | 140°/140° |
View Distance | >5m |
Grey Scale | 14 bit |
Drive Mode | 1/6S |
Frame Frequency | >3840Hz |


Display Scale | 16.7 m |
Brightness Adjustment | 0-100 levels adjustable |
Max Power Consumption | 650 W/m² |
Ave Power Consumption | 200 W/m² |
Cabinet Structure Material | Carbon Fibre |
Control Mode | Synchronous display with control PC by DVI |
Support Input | Composite,S-Vido,Component,VGA,DVI,HDMI,HD,SDI |
Operation Power | AC100-240 50/60 Hz |
Operating Temperature | -20 ℃ to +50℃ |
Operating Humidity | 10-95% RH |
Operating Life | 100000 hours |

【Eye-Catching 】You don’t have to worry about it not being dazzling enough. It
adopts WIFI remote control programming technology, supports
barrier-free programming on mobile phones and computers within 30
feet. Supports text, date and time input and editing, and can set
more playback modes such as scrolling playback, flashing, and
static playback. A variety of colorful dynamic fonts, borders,
animated background settings, and continuous flashing lights can
create a strong visual impact , successfully helps you attract
widespread attention in various public places.
【Outdoor High Brightness Digital Signage】Using high quality RGB lamp beads, the brightness is up to 5000CD,
stable performance, clear fonts and pictures without flickering,
bright colors, even from 70 feet away, people can see your signage
at a glance, attracting more foot traffic for you. Adjustable
brightness, can be used indoors.
【Premium Quality Design】Housed in a durable aluminum case, our LED signs offer both
durability and style. Easily program messages through PC software,
with convenient updates via U-disk or WIFI. Note that the PC
software supports Windows only, but you can also program messages
on-the-go using smartphone apps for iPhone and Android—simply scan
the code to download. Elevate your outdoor messaging with our
versatile LED signs.
【Cutting-Edge LED Technology】Elevate your outdoor presence with our SMD technology-driven
full-color LED Sign. Seamlessly switch between vertical OPEN,
vertical LED SIGN,horizontal LED DISPLAY, and more. With a 10mm dot
distance and a vivid display resolution of W160 x H64 dots, this
sign is designed to captivate attention effectively. Illuminate
your message in vibrant hues, making it an irresistible focal point
for passersby.
