Powerline Tools Bolted Type Steel Clamp Aluminum Alloy Bolted Type Tension Clamp

Categories Powerline Tools
Brand Name: HANYU
Model Number: P-NLL-2
Certification: ISO9001
Place of Origin: China
MOQ: 30pieces
Price: Negotiable
Payment Terms: L/C, T/T
Supply Ability: 10000pieces/month.
Delivery Time: 15-35days
Packaging Details: Case
Type: Aluminum Alloy Bolted Type Steel Clamp
Dimensions L1: 210mm
Dimensions L2: 160mm
Quantity of U bolt: 3
Dimensions M: 16mm
Dimensions C: 22mm
Suitable diameter of Conductor: Φ8.2-Φ17.0
Failure load: 70kN
  • Product Details
  • Company Profile

Powerline Tools Bolted Type Steel Clamp Aluminum Alloy Bolted Type Tension Clamp

Powerline Tools Bolted Type Steel Clamp Aluminum Alloy Bolted Type Tension Clamp


Technical features:
  • There is no need to cut the wire, and it is fixed with several U-shaped screws, but the grip strength is not as good as the compression type.
Product advantages:
  • Installation is easy, there is no need hydraulic equipment;
  • Each type is applicable to a wide range of conductors.
  • Bolted Tension Clamp is used for fixing the terminal of the conductor and ground wire on the tension tower. They can bear all or part of the tension of the conductor and ground wire.
  • Usage scenarios: Transmission line system, substation system, distribution system
Technical Details
Catalog N0.

Suitable diameter of Conductor

mm

Dimensions mmQuantity of U bolt

Failure load

kN

L1L2CM
P-NLL-1Φ7.6-Φ16.21281051916240
P-NLL-2Φ8.2-Φ17.02101602216370
P-NLL-3Φ14.1-Φ18.02202132216370
P-NLL-4Φ13.6-*Φ25.03203203018490
P-NLL-5Φ16.0-Φ32.038038036225100
P-NLL-6Φ28.5-Φ46.548048050226100

Typical Parameters(Trapezoid structure)
Code

Structure

Nos/mm

Areas

mm2

Diameter

mm

Breaking
load

kN

DC
resistance at 20

Ω/km

Weight

Kg/km

Curent

capacity A

AlSteelTACIRZTACIR
160/4018/3377/2.65199.1617.0465.060.175973071957
200/4517/3877/285244.6218.8776.870.14128838901105
200/5017/3877/2952478119.0180.390.14099068921110
250/4518/4207/285294.0420.6482640.1141101910171268
250/4018/4.137/275290.9620.5181120.114399610141264
240/5518/4.137/3.202974320.8293120.1169108310071138
240/5018/4717/3.00290.6220.5588.130.1157103210001131
315/5518/4717/3.20396.922315104.060.0907126611821479
315/5018/4717/3.0036310229197.20.091123211761471
330/6018/4817/330386.952368109700.0869132912161522
350/5520/4717/3.20404.772419109330.0819137912621580
