| Categories | Laser Welding Machine |
|---|---|
| Cooling Type: | Air-Cooling |
| condition: | New |
| Applicable Material: | Stainless Steel, Metal, Aluminum, Carbon Steel, Steel, Brass |
| Laser Type: | Fiber Laser |
| Output Power: | 1200W |
| usage: | Metal Stainless Steel Aluminum Welding |
| Welding Mode: | Pulse, Continuous |
| Welding Speed: | / |
| Place of Origin: | Hubei, China |
| warranty: | 1 Year |
| weight (kg): | 30 |
| key selling points: | Multifunctional |
| Product name: | Handheld Laser Welding Machine |
| Application: | Metal Stainless Steel Aluminum Welding |
| Laser power: | 800W / 1200W |
| Function: | 3-in-1 |
| Cooling System: | Air Cooling |
| Laser wavelength: | 1080±10nm |
| Advantage: | Mini Size |
| Power Supply: | 220VAC/50Hz/60Hz |
Model | EW-800R | EW-1200R | |
Laser Power | 800W | 1200W | |
Working Mode | Continuous / Modulated / Pulsed / Line Array / Timed | ||
Laser Wavelength | 1080nm±10nm | ||
Power Stability | <5% | ||
Fiber Length | Standard 5±0.5 m (Optional 10 m) | ||
Alignment Laser Wavelength (nm) | 650 nm | ||
Laser Response Time | <10 μs | ||
Cooling Method | Air Cooling | ||
Cooling & Protection Gas | Inert Gas | ||
Power Requirements | 220 V AC, 50/60 Hz | ||
Total Power Consumption | ≤4.0 kW | ||
Operating Temperature Range (°C) | -10°C to +40°C | ||
Operating Humidity Range (%) | ≤85% RH | ||
Net Weight | <30 kg | ||
Cabinet Dimensions | 250 × 520 × 490 mm | ||
Red Beam Indicator | Built-in Coaxial Red Laser | ||
|
